Overview
CLAAS LINER hay rake is designed for reliable operation at maximum efficiency while protecting the soil and grass cover. Choose from a wide range of single, twin or quad rotor swather that meet the needs of every farmer and contractor.
Consistent delivery of peak performance
The CLAAS LINER features a continuously lubricated, maintenance-free rotor dome assembly in all models.
Its spheroidal graphite iron construction gives the cam track the strength required to withstand any load. The cam track arms have a triple-bearing system in the 14-tine arm rotor dome assembly, and a dual-bearing arrangement in the 12-tine arm version.
Moreover, the LINER is an incredibly low-maintenance machine, with a 250-h lubrication interval for the universal joints of the drive shafts, and a 50-h interval for the travel drive shaft.
Top forage quality
The CLAAS LINER remains firmly grounded even at higher speeds. The cardanic rotor suspension adapts effortlessly to uneven terrain and optimum ground-contour following protects both the soil and the crop.
Sturdy, flexible tines and the adjustable swathing rotor angle ensure clean and complete pick-up of the crop material.
The end result is a perfect swath, even at high travel speeds.
Specifications
-20 LINER models in series
-Trailed or 3-point linkage options
-3.5 m - 15 m working width
-Single, Twin or Quad rotor options
-Transport height below 4.00 m
