We know that a wheel loader is a key part of the on-site process. That's why the new JCB 427 is built on a foundation of quality and reliability. It's also designed to perform great feats of productivity, offering superb performance without the time-consuming inconvenience of a DPF.
Max Engine Power 133KW
Bucket Capacity2.4m3
Max. Operating Weight13603kg
Perhaps the biggest change to this wheel loader is the introduction of JCB's latest Command Plus cab, which means, quite simply, best-in-class comfort, visibility, ergonomics and quietness. Expect superior serviceability and safety too.
The JCB 427 Wastemaster wheel loader's Auto Idle feature returns the engine to 700rpm after 30 seconds of inactivity. Eco Mode caps engine speed at 1800rpm for reduced fuel consumption. Productivity nonetheless remains formidable.
A hydraulic cooling fan automatically reacts to ambient temperature and adjusts the fan speed to optimise energy and reduce fuel consumption. An additional benefit of this setup is lower noise levels.
Our torque lock-up 5-speed transmission option gives 100% efficiency in gears 2 to 5 for improved fuel consumption on your wheel loader. Closer gear ratios provide lower engine speed in each gear.
It's easy to get to the engine on a new JCB 427 Wastemaster wheel loader with a large automatic opening single-piece bonnet. Accessing the diesel and DEF tanks is similarly straightforward via the lockable grille at the rear of the machine.
Heating and ventilation filters are conveniently located behind an external access panel. You can check washer fluid level, engine oil and coolant from inside the cab, with all other routine checks and grease points located at ground level.
A cyclonic engine fan scavenge filter provides four times the filtering capacity of a standard air filter. It's a longer life system, with fewer components and a higher level of efficiency, making for better engine protection.
Most Tier 4 Final/Stage IV engines use a Diesel Particulate Filter (DPF) that can cost a lot of money and time when it needs replacing. The Cummins engine is DPF-free, reducing your servicing and running costs.
By using top components in the JCB 427 Wastemaster wheel loader (Cummins engine, ZF transmissions and axles, Rexroth pumps and Parker valve blocks), we've built in long service life as standard.
Powerful twin variable displacement piston pump hydraulics can circulate a massive 264 l/min for fast cycle times and excellent multi functioning capability on the JCB 427 Wastemaster wheeled loader.
The Cummins QSB 6.7-litre engine achieves maximum engine power (133kW) and peak torque (841Nm) at low revs for excellent response. A variable geometry turbo gives increased performance at low engine speed for improved cycle times and tractive effort.
The JCB 427 Wastemaster wheel loader's articulation joint has a heavy-duty box section, a heavy-duty centre pin and oversized bush, as well as twin taper roller bearings on the bottom box joints. This setup can easily tolerate vertical and horizontal loadings.
Finite element analysis, as well as extensive endurance and rig testing ensure superior structural strength and durability. Cold cell testing guarantees starting performance down to -20°C.
High tolerances and accurate location of pins and bushes are assured with JCB's precision machining techniques. State-of-the-art manufacturing processes like robot machining, precision paint technology and innovative assembly techniques help to achieve the very highest levels of build quality.
