The JCB Fastrac 4220 is a brand new generation of tractor, raising performance and productivity levels to new heights with seamless control, faster operating speeds, multiple implement mounting points and unique all-round self-levelling suspension.
Max Engine Power 175KW
Max. Lift Capacity8000kg
The design draws on 25 years' experience in developing the unique JCB Fastrac tractor features and capabilities like equal sized wheels, 50:50 weight distribution and 4-wheel disc braking with ABS. With unrivalled productivity, versatility, comfort, safety and serviceability the JCB Fastrac 4220 really is all the tractor you'll ever need.
The JCB Fastrac 4220 tractor is perfectly suited to a wide variety of applications in grassland, arable, haulage and livestock operations alike. Look no further for the best return on investment.
Compare Fastrac with conventional tractors and you'll find that JCB tractors offer faster in-field speeds, greater load carrying capacity, quicker headland turns and faster transfer speeds, potentially saving several working days a year.
Turning at the headland is much faster with four-wheel steering and a minimum turning circle below 10 metres.
Carry an extra 2.25m³ of seed on the rear deck to reduce drill refilling stops to once per day. Put the drill hopper up front for ultimate capacity, 50:50 weight distribution, and scope for using wider power harrow-seed drill combinations.
A new AGCO Power 6.6-litre six-cylinder engine provides the JCB Fastrac 4220 tractor with proven fuel efficiency, a maximum 235hp (175kW) of power and 950Nm of torque. The whole driveline offers plenty of grunt at low revs, maximising performance and efficiency.
New CVT transmission ensures optimum use of power and torque, with seamless acceleration and power delivery, ideal speeds for every situation, and ultra-fine speed control for top-quality work with all implements.
Tailor your transmission and engine control strategy using the Fastrac's touch screen controller “ prioritise power and productivity, fuel economy, fixed engine/PTO speed or fuel-efficient road travel.
Active Traction manipulates your tractor's torque output to keep the tyres gripping for maximum pulling power with minimum wear.
The SCR emissions system used on these tractors is fuel-efficient technology that's been tried and tested on other models in the JCB Fastrac range.
JCB Fastracs are fast on the road and in the field at low engine revs: cruise at 60km/h at 1600rpm or drive for maximum fuel economy at 50km/h with just 1400rpm on the clock (tyre dependent).
The JCB Fastrac 4220 tractor's unique self-levelling rear axle suspension is now matched by a new hydraulic front system that maintains correct ride height wherever the implement is mounted. Mounted implements are also cushioned from shocks and jolts by this system.
Active suspension quickly responds to coupling a linkage-mounted implement or a de-mount sprayer/spreader, restoring ride height, wheel travel and stability with a stiffer spring rate to support the extra weight.
A smooth-riding chassis provides a stable platform for spraying and spreading with consistent working heights and high operating speeds. Unique side-to-side active levelling promotes maximum stability, driver confidence and productivity, particularly in difficult terrain.
The JCB Fastrac 4220 tractor is a real Swiss Army knife of tractors in a small but powerful package. Make use of five implement positions, including the chassis for a front loader, to do more operations in one go.
Maximum Permissible Vehicle Weight is up to 14 tonnes (depending on territory/configuration) with the ability to mount up to 4 tonnes on the rear deck. So these tractors can carry loads more, with bigger implements and fewer refills.
There's a new three-point linkage system on the Fastrac 4220, featuring up to 8,000kg lift capacity with new geometry ensuring plenty of muscle and lift for large implements. Front linkage capacity is now boosted to 3,500kg.
