The JCB Hydradig 110W is the first true wheeled excavator designed for purpose, from the ground up. The result is an engineering masterpiece. Designed without compromise, we are the first to move the engine, tanks and ancillaries to the chassis making the JCB Hydradig 110W first for visibility, stability, manoeuvrability, mobility and serviceability.
Max Engine Power 81KW
Dig Depth0.31m
Max. Operating Weight11457kg
The JCB Hydradig 110W really does have innovation running right through the heart of it. Read how the features and their benefits will transform the way you and the whole industry works.
In today's world where space is at a premium, compact dimensions and all-round visibility have become increasingly important. The JCB Hydradig 110W lets you enjoy total all-round visibility with the ability to see all four wheels from operator seat plus a 1m perimeter around the machine at ground level.
With the 81kw T4 EcoMAX engine and other components now housed in the chassis, the counterweight has been radically reduced making the tailswing just 120mm. This allows the operator to view stabilisers, dozer and trailer hitch from inside the cab without needing to slew the machine.
With low-level glass and optional LED work lights, it makes the JCB Hydradig first for easier and safer operating in tight, crowded worksites, day and night.
On urban worksites, safety is rapidly becoming the number one priority. The JCB Hydradig 110W gives best-in-class over the side stability when digging lifting or slinging, compared to conventional tailswing competitors. This is all achieved with a minimal tailswing of just 120mm.
Engine and double skinned tanks are mounted on all steel chassis which creates a lowered centre of gravity. A 50/50 weight distribution between the axles also significantly reduces nod and pitch whilst roading. Together they provide extra operator confidence and productivity when lifting and carrying materials around site as well as providing unparalleled stability on the road.
This all makes the JCB Hydradig 110W first for stable working.
In a world where time is money, a top speed of 40kph and stepless transmission from a T4 81kW EcoMAX engine lets you travel to and between sites quicker and in comfort. It also eliminates the need to hire or purchase a lorry for transport.
3 mobility modes allow the operator to set the JCB Hydradig 110W for any task. Highway mode isolates the upper structure for travelling at up to 40kph, site mode limits the machine to 20kph with all hydraulic services active, whilst creep mode has a speed limiter for the most precise jobs.
Optional trailer hitch with a 3.5T towing capacity and JCB approved warranty allows you to take all your attachments to site (Subject to compliance with Local Laws and Regulations relating to towing and operator/driver licensing requirements) and Auto-idle as standard reduces revs when the machine is idling to save fuel. This all makes the JCB Hydradig 110W first for getting to work.
In even the most confined urban sites, 4-wheel steer, 2-wheel steer and crab steer as standard make operating easy, allowing you to work in tighter confines safer than ever before.
A best-in-class turning circle of under 4m lets you work comfortably within a single carriageway whilst a reverse steer option lets you change the back of the machine to the front when working in a single lane.
Reduced front swing and minimal tailswing of just 120mm allows you to work closer to walls and a Kingpost means you can dig parallel without compromise to stability. This increases versatility and productivity, making the JCB Hydradig 110W first for working in today's urban world.
