467 ZX Wheel Loader

There are many reasons to choose the top-of-the-range 24-tonne JCB 467 ZX wheel loader . It's productive, efficient, easy to maintain and extremely durable.

Max Engine Power 239KW

Bucket Capacity4.2m3

Max. Operating Weight23800kg

Sales Enquiry Parts


The 10.8 litre 6 cylinder Cummins QSM11 engine is Stage 3a/Tier 3 compliant and produces high power (216 kW) and torque (1478 Nm) at low revs. That helps the 467 ZX front-end loader to increase productivity by up to 40% and lower fuel use by up to 20%.

There's also an intelligent clutch cut-off feature that gives maximum hydraulic performance and limits vehicle speed when loading.


Cummins QSM11 engine produces high power, torque and economy. An intelligent clutch cut-off feature gives maximum hydraulic performance and limits vehicle speed when loading. Limited slip or automatic differential lock axles achieve traction in all conditions. Transmission options can perfectly match your application.

The cabin has space, protection (ROPS and FOPS), excellent visibility, intuitive controls and extensive stowage areas. A stylish full-colour LCD dash display with analogue dials. Electro-hydraulic servo controls make loader end handling easy. Climate control and air conditioning heating options are available.

The 467's 216kW (290hp), 6-cylinder diesel engine produces high power and torque at low revs. The 10.8 litre unit complies with Stage 3A/Tier 3 and features a reliable Celect electronic injection system for both performance and efficiency. Optional automatic idle shutdown is available to reduce fuel usage.

The JCB 467's standard 4-speed ZF fully automatic powershift transmission provides stepless gear changes and smooth operation. The optional 5-speed unit allows lower engine speeds with smaller steps between gears, reducing fuel consumption.


The JCB 467's z-linkage loader design means breakout forces are huge and shovel corners are highly visible. High dump angles provide excellent discharge and retention, while maintenance is reduced through minimising pivots. Load sensing hydraulics. For the ultimate in precise, efficient loader control, JCB's innovative variable displacement pumps feed a load-sensing valve block, only consuming power on demand.

Smoothride suspension system.

The 467's Smoothride load suspension system limits shock loadings. This reduces material spillage and structural stresses, increasing operator comfort as well.

Loader settings.

Operating a 467 is simple and efficient; return-todig, arm height limitation and float functions are always at hand. Disabling the aids is possible with just the flick of a switch.


ROPS/FOPS safety structure.

Operator safety is paramount! The JCB 467 cab is isolator-mounted, compliant with ROPS/ FOPS standards, and positively pressurised to keep out dust. Air recirculation filters include fresh air, and options of carbon and P3 “ HEPA.

LCD from JCB. The 467 has a stylish, modern central dash display combining analogue dials and a colour LCD screen. The screen can display operating, service and machine health information, and much more besides.

Easy loading.

The JCB 467's loader end is electrohydraulically controlled for low effort precision lever operation, with integrated kickdown and differential lock (if fitted). Forward/reverse direction control is just a finger tip away.

A productive climate.

JCB's air conditioning or automatic climate control options allow operators to select the perfect working temperature.

The best seats.

JCB has a range of seat options, with choices like mechanical or air suspension, vinyl or fabric bases. Our Actimo XXL option is heated, with air suspension, lumbar support, armrests, backrest extension, a headrest and full adjustment for premium comfort.

Visibly better.

The 467 has a 3-piece laminated front screen for excellent visibility. Rearward visibility is a step forward too, thanks to interior mirrors, heated exterior mirrors, an optional reverse camera and a sloping rear bonnet design.
