435S Agri Wheel Loader

The JCB 435S Agri wheel loader is designed to maximise productivity on the farm. Built with a high power-to-weight ratio using only the finest components “ a Cummins engine, ZF transmission and axles, and Rexroth pumps “ the 435S will last the distance. And, with 230hp, 945Nm and a 264 l/min hydraulic circulation, it'll perform to the max throughout.

Max Engine Power 172KW

Bucket Capacity2.7m3

Max. Operating Weight13688kg

Sales Enquiry Parts


It's all-day comfortable - a comfy operator is, after all, a productive one. It's also safe, serviceable and, with features like Eco mode and Auto Idle, it's highly fuel-efficient too.


The Cummins QSB 6.7-litre engine achieves maximum engine power (172kW) and peak torque (945Nm) at low revs for excellent response.

A variable geometry turbocharger provides increased performance at low engine speed for improved cycle times and tractive effort.

JCB's optional quickhitch makes attachment changing quick and efficient. The quickhitch is designed to be compatible with aftermarket attachments too.

Powerful twin variable displacement piston pump hydraulics can circulate a massive 264 l/min for fast cycles and excellent multi-function capability.

The high torque (HT) arm design on the 435S wheel loader gives great visibility to the loader end, as well as offering parallel lift, making it ideal for multi-attachment use.Constant torque throughout the full carriage rotation provides excellent power and attachment control. Choose a HT high lift on the 435S and you can use the machine for higher loading height applications (hopper, trailer and spreader loading).


A hydraulic cooling fan automatically reacts to ambient temperature and adjusts the fan speed to optimise energy and reduce fuel consumption. An additional benefit of this setup is reduced noise levels.

Eco Mode caps engine speed at 1800rpm for reduced fuel consumption. Productivity nonetheless remains formidable.

Our torque lock-up 6 speed transmission gives you up to 100% efficiency in all gears for improved fuel consumption. Closer gear ratios provide lower engine speed in each gear.

Wheel speed braking means the brakes rotate at the same speed as the wheels for heat and drag reduction, as well as improved fuel economy and access for maintenance and repairs.

Unloaded spool valves in the valve block mean that arms lower under gravitational, not hydraulic force, reducing fuel consumption.

JCB's innovative variable displacement pumps feed a load-sensing valve block which only consumes power on demand, providing precise, efficient loader control.


You'll immediately notice the totally redesigned ROPS structure; this has allowed the A pillars to be moved to the same width as the rear of the cab, providing a larger interior with a superb panoramic front windscreen. All switches and auxiliary controls are now located on the right-hand A-pillar for easier access.

Using your machine's simple, dedicated menu interface is easily done with an intuitive optional rotary controller.

Operating your 435S loader is now easier than ever. All of the controls are seat-mounted, even going as far as to move with the seat suspension. You can also select the control system that's best for your operators: choose from single lever joystick or multi-lever configurations, all using electro-hydraulics for the ultimate in precision.

There are two full colour LCD screens to navigate the operating menus, one of which doubles as a monitor for the optional rear-view camera and CommandPlus control menu.

To keep the operator environment comfortable for working at all times, we've positively pressurised the cab to eliminate dust and fumes.
