JCB understands that a wheeled loading shovel is a crucial part of any on-site process. For this reason, the new JCB 411 wheel loader is built on a foundation of quality and reliability.
Max Engine Power 81KW
Bucket Capacity1.4m3
Max. Operating Weight8722kg
It's also designed to perform great feats of productivity, offering superb performance without the time-consuming inconvenience of a DPF. Perhaps the biggest change to this wheel loader is the introduction of JCB's latest Command Plus cab, which means, quite simply, best-in-class comfort, visibility, ergonomics and quietness. Expect superior serviceability and safety too.
The JCB 411 wheel loader features 123 l/min double gear pump hydraulics for fast cycle times and excellent multifunctioning capability. A variable geometry turbocharger, meanwhile, provides increased performance at low engine speed for improved cycle times and tractive effort.
This loading shovel is fitted with a JCB EcoMAX 4.4-litre engine, which produces peak power (80 kW/108 hp) and torque (516 Nm) at low revs for excellent response.
There's no need to worry about wasting time and money replacing diesel particulate filters (DPFs). EcoMAX meets Tier 4 Final/Stage IV legislation using only exhaust gas recirculation (EGR) and selective catalytic reduction (SCR). This setup also improves fuel economy.
On the new JCB 411 wheel loader, you'll find the rear-view mirrors mounted in front of the A-pillars for improved visibility. Interior mirrors, heated exterior mirrors and bonnet mirrors combine to offer excellent views all around your wheeled loading shovel.
Access steps on this loader are inclined and equally spaced, complemented by well positioned grab handles for three points of contact at all times. Non-slip walkways and additional grab handle options allow for safe movement around the machine.
Full fender coverage flaps have been carefully designed to keep forward spray to a minimum for all tyre options. This increases safety and decreases debris build-up on your wheeled loading shovel.
The cab is isolator-mounted, compliant with ROPS/FOPS standards, and positively pressurised against dust. You can choose from fresh air or carbon filters as well. The battery and toolbox are lockable for added security.
It's easy to get to the engine on a new JCB 411 wheel loader via the compact single-piece bonnet. Accessing the diesel and DEF tanks is similarly straightforward; the two filler points are separated to avoid accidental cross-contamination when refilling.
You can check washer fluid level, engine oil and coolant from inside the cab, with all other routine checks and grease points located at ground level. This makes life both easier and safer.
A cyclonic engine fan scavenge filter provides four times the filtering capacity of a standard air filter. It's a longer life system, with fewer components and a higher level of efficiency, protecting your wheeled loading shovel's engine from unnecessary wear.
To prove how good EcoMAX engines are, we've tested them for 110,000 hours in 70 different machines across the toughest applications and environments. There's a large 116-litre fuel tank fitted, which ensures maximum working hours between refills.
Most Tier 4 Final/Stage IV engines use a Diesel Particulate Filter (DPF) that can cost a lot of money and time when it needs replacing. The EcoMAX engine is DPF-free, reducing your servicing and running costs.
