The 7500 kg JCB 940 rough terrain forklift is powered by our highly efficient 55 kW Dieselmax engine and has a 4000 kg lift capacity.
Max Engine Power 55KW
Max. Lift Capacity4000kg
Max. Lift Height6.7m
It has several mast options ranging from 3.6 to 6.7 m so you can tailor your 940 rough terrain forklift to the perfect lift height.
What's more, JCB's Synchro Shuttle transmission gives fast, smooth directional changes and a sideshift feature means you can accurately place materials on scaffolding.
Daily checks and greasing are carried out easily at ground level. All filters (engine oil, fuel, transmission, hydraulic oil and air) are near each other for faster servicing too. The air filter is a cyclonic design that ejects dust and debris by centrifugal force resulting in cleaner air and longer air filter life.
The hydraulic tank on a new JCB rough terrain forklift is very accessible, and can be filled from ground level. The same is true of the diesel tank, which also has an integral pre-filter for protection against dirty fuel.
JCB LiveLink telematics technology offers benefits like real-time data that allows you to monitor and manage machines remotely. You can also monitor any issues and get them resolved swiftly by your JCB dealer, thus boosting productivity throughout the working day.
The 4.4-litre EcoMAX T4 Final-compliant engine in a JCB rough terrain forklift produces peak power (74hp/55kW) and torque (400Nm) at just 1200 rpm for great responsiveness. A fixed geometry turbo further enhances low-rev performance for improved power and tractive effort.
You can fine-tune a JCB Rough terrain forklift to any application and terrain. Lift capacity of the 940 is 4000kg; tyres are available in large diameter traction or industrial; long pallet forks in either 1067mm or 1200mm; and either 2WD or 4WD.
We offer an optional single or double acting mast auxiliary; in turn, these facilitate a huge range of productivity-boosting options. And, because different applications demand different sizes of mast, you can specify 3.6, 4.5, 5.5 or 6.7m variants.
As part of JCB's Vertical Integration Strategy, we build the engine, transmission, hydraulic rams and cab of every rough terrain forklift so that they'll work in perfect harmony. The end result is minimum compromise, optimum performance.
The large, spacious cab of a JCB rough terrain forklift boasts left and right grab handles with wide-opening doors; standard-fit tinted glass which reflects 30% of solar energy; and a new 3-speed heater fan for improved demisting/de-icing of the windscreen.
For all-day productive comfort, we offer both suspension and air suspension seating options that can be adjusted to different operator requirements or tasks. When lifting or placing loads, our optional sideshift carriage makes things even easier.
In-cab noise levels are reduced. New backlit laser-etched switches aid recognition and night visibility, while simple lever controls ensure total command of mast and auxiliary functions.
Visibility is excellent, courtesy of direct glazing, fold-back rear doors, a low bonnet, high cab mounting position, a large roof screen, a slimline outer mast section, and large front and rear windscreens. Optional front and rear work lights provide ultimate visibility.
A zero tail swing design means that when the rear tyre of a JCB forklift has cleared an obstacle on full turn, you can be safe in the knowledge that the rear counterweight will clear it too. This means our machines are ideal for working in confined areas.
Our rough terrain forklift hydraulic cylinders have friction-welded eye-ends for extra strength, plus all pivots use hardened pins. Masts are made from heavy-duty channel and I-section steel, alongside heavy-duty chains and guide roller bearings that are sealed for life.
The one-piece fully welded chassis on a JCB forklift maximises strength and minimises weight, while axles are the same heavy-duty units we fit to our backhoe loaders and Loadalls.
